AMT Electronics Bricks D-Lead tube Guitar preamp

C$399.99

AMT Bricks D-LEAD – For high gain lovers, a-la Diezel.

Availability: 2-3 Days

Brand: AMT Electronics

Product Code: Bricks D Lead

Tags: amt preamp bricks pre-amp d-lead

AMT Bricks D-LEAD

AMT Bricks D-LEAD – For high gain lovers, a-la Diezel.

Names used in this document are trademarks of their respective owners, which are in no way are associated or affiliated with AMT Electronics. These trademarks of other manufacturers were used to identify products whose sounds were reviewed in the making of this product.

Features:

– Small dimensions (Snickers size).

– The full set of regulation knobs (Gain, Treble, Middle, Bass, Volume), despite the compact design.

– The really high anode voltage (+250…300V).

– The implementation of either full tube or hybrid (tube + semiconductors) circuit design with efficient emulation of vacuum triode cascades by semiconductor components.

– Ability to use overloaded channels in preamp mode (connected to the Amp’s Return) or in the drive pedal mode (connected to the amp’s Input).

– The pedal can control other devices or be controlled by other devices. It has special CTRL A and CTRL B connectors.

– X-Lead/X-Clean preamps can be used as separate devices, as well as a group of preamps connected in a serial chain (both via the audio path and the control connectors CTRL A and CTRL B). In the latter case, turning on any preamp in the chain will turn off all other connected preamps, that is, they’ll be switched to TRUE BYPASS mode. Thus, without the use of any external devices, it is possible to implement a multichannel preamp from almost any reasonable number of preamps of the X-Lead/X-Clean line, switched by the “one of” rule.

– In addition, X-Lead / X-Clean preamps, along with other devices, can be used as part of an AMT Bricks pedalboard. Full information about the pedalboard will be presented later.
COMPATIBLE TUBES

At the discretion of the manufacturer, a preamplifier can be equipped with a tube of one of the following types: AMT-12АХ7WS, 12АХ7, ECC83 (or another 12AX7 compatible).

Technical
Pedal Type	Tube Preamp
True Bypass	Yes
Power Source	12Volts DC center negative (not included)
Batteries	No. Only runs on 12V DC power source
Current Draw	300 mA
Inputs	1/4 TS CTRL B -TRS 3.5mm external control connector (input/output)
Outputs	1/4 TS CTRL A -TRS 3.5mm external control connector (output)
Height	47 mm
Depth	95 mm
Width	55 mm
Weight	270 gram
